PRODUCT NAME
SYHCEMLS 400
Tool Material
HSS Cobalt
Coating
Uncoated
Recommendation Good
Steel
Stainless Steel
Cast Iron
Aluminium
Helix
30°
Product Description
HSS Cobalt Long Series End Mill 4 Flute Uncoated
| Part No. | Mill Dia (D1) | Cutting Length (L1) | Shank Dia (D2) | Overall Length (L2) |
|---|---|---|---|---|
| SYHCEMLS 400 030 | 3.0 | 15.0 | 6.0 | 60.0 |
| SYHCEMLS 400 040 | 4.0 | 20.0 | 6.0 | 65.0 |
| SYHCEMLS 400 050 | 5.0 | 25.0 | 6.0 | 70.0 |
| SYHCEMLS 400 060 | 6.0 | 25.0 | 6.0 | 70.0 |
| SYHCEMLS 400 080 | 8.0 | 35.0 | 8.0 | 85.0 |
| SYHCEMLS 400 100 | 10.0 | 45.0 | 10.0 | 100.0 |
| SYHCEMLS 400 120 | 12.0 | 55.0 | 12.0 | 115.0 |
| SYHCEMLS 400 140 | 14.0 | 55.0 | 12.0 | 115.0 |
| SYHCEMLS 400 160 | 16.0 | 65.0 | 16.0 | 130.0 |
| SYHCEMLS 400 160-XL | 16.0 | 100.0 | 16.0 | 160.0 |
| SYHCEMLS 400 180 | 18.0 | 65.0 | 16.0 | 130.0 |
| SYHCEMLS 400 200 | 20.0 | 75.0 | 20.0 | 145.0 |
| SYHCEMLS 400 200-XL | 20.0 | 100.0 | 20.0 | 180.0 |
| SYHCEMLS 400 200-XXL | 20.0 | 150.0 | 20.0 | 230.0 |
| SYHCEMLS 400 220 | 22.0 | 75.0 | 20.0 | 145.0 |
| SYHCEMLS 400 250 | 25.0 | 90.0 | 25.0 | 165.0 |
| SYHCEMLS 400 250-XL | 25.0 | 150.0 | 25.0 | 250.0 |
| SYHCEMLS 400 280 | 28.0 | 90.0 | 25.0 | 165.0 |
| SYHCEMLS 400 300 | 30.0 | 90.0 | 25.0 | 165.0 |
| SYHCEMLS 400 320 | 32.0 | 95.0 | 32.0 | 180.0 |
| SYHCEMLS 400 320-XL | 32.0 | 150.0 | 32.0 | 250.0 |
| SYHCEMLS 400 320-XXL | 32.0 | 200.0 | 32.0 | 280.0 |
